Catalina Destination 40BHTS Park Trailer by Coachmen

It's never been easier to build the RV of your dreams!

Use the form below to select the equipment & d├ęcor that's perfect for you. When you are done, you can get your very own

customized price quote by clicking the "Get The Price" button.

Equipment
Standards
Specifications
  • Factory Standards
    Universal 600W Solar Prep w/ Installed Roof Panel Port, LCI One Control, Siphon 360 Roof Vent, Glass Step-In Shower w/ ABS Surround, 5/8" Tongue and Groove Stabledeck Flooring, Bedroom USB and Outlets, Living Room and Master Bedroom Ceiling Fans w/ Wall Switch (N/A on all floorplans), Friction Hinge Door(s), Power Vent Fan in Living Room AND Bathroom
    Fireplace in Living Room, Theater Seating with Phone Charger Console (Per Floorplan), Serta Mattress, Washer/Dryer Prep (Per FP), LP Quick Connect, 10 Gallon G/E DSI Water Heater, Exterior TV Hookups, Black Tank Flush, Hot/Cold Outside Shower, XL Grab Handle at Main Entrance, Battery Disconnect, 4,000 Lumen Interior Touch Lighting
    Stainless Microwave, 21" Stainless 3-Burner Gas Range with Metal Back-Lit Knobs, 15,000 BTU GE A/C, Gas/Electric DSI Water Heater, Thermofoil Countertops w/ Smooth Drop Edge, Deep Basin Farm Style Sink, Stainless Steel Drying Rack, Stone Backsplash, (2) USB and (2) 110 outlets
    JBL Aura Head Unit, 2 JBL Premium Interior Speakers, 2 JBL Premium Exterior Speakers, Full 4G LTE/Wifi Booster/Wifi Extender Prep
    Roadside Assistance
    Interior Decor
    Factory Options
    non ducted
    N/A with Non-Self Contained Option
    House Type Toilet, Fresh Water Tank and Pump, No Black and Grey Tanks with a Direct Dump
    200W Panel w/ 30 AMP Solar Controller
  • <!– 11/08/23 –>

    EXTERIOR FEATURES

    • Black Tank Flush
    • Battery Disconnect Switch
    • Siphon 360 Holding Tank Roof Vent
    • Heavy Duty Standard Tongue Jack
    • Hot/Cold Outside Utility Shower w/ Hands Free Holder
    • (2) 20 lb. LP Tanks
    • Black ABS LP Bottle Cover
    • LP Quick Connect
    • Flush Mount Baggage Doors w/Radius Corners
    • Stabilizer Jacks
    • G20 Tinted Privacy Windows
    • Premium JBL Exterior Speakers
    • Friction Hinge Door
    • Radius Cornered Fiberglass Entry Door
    • Exterior 110V G.F.C.I Protected Receptacle
    • Exterior RG-6 Coax Cabling and Satellite Prep
    • Exterior TV Hookup
    • Rain Gutters with Drip Spouts
    • Flip Down Steel Steps
    • XL Swing Arm Entry Assist Handle (Main Entrance Only)
    • Residential Sliding Glass Patio Door
    • Large Front Bay Windows
    • Bottle Openers (Exterior Camp Kitchens)
    • Pets - “Leash Link” Quick Hookup D-Ring
    • Universal Solar Prep w/Roof & Chg. Contoller Connections & Wiring
    • Rear Ladder Prep

    INTERIOR FEATURES

    • One Control Smart RV Tech Monitor Panel (uses LCI OneControl - App)
    • RV-LINK 4G LTE Remote Connect, WiFi, Booster, and Extender Prep
    • Premium Audio JBL Aura Cube Multi-Zone Function Media Center
    • Premium JBL Interior Speakers
    • 18 Cu. Ft. Residential Refrigerator
    • Seamless Thermofoil Countertops Throughout
    • Deep Basin Farm Style Sink
    • Residential Kitchen Faucet w/Pull Down Sprayer
    • Stainless Steel Drying Rack
    • GE Stainless 3-Burner Gas Range with Metal Back-Lit Knobs (21” Oven)
    • Range Hood
    • GE Stainless Microwave W/Glass Turn Table
    • Congoleum Woodplank Linoleum Flooring
    • 4000 Lumin LED Interior Touch Lighting
    • Directional Master Bed Reading Lights
    • Theater Seating with Phone Charger Console (Per Floorplan)
    • Bunkroom Jackknife Sofa (40BHTS)
    • Designer Wall Light Main Slide Room
    • Hard Valance Window Treatments
    • Pedestal Thermofoil Dinette Table
    • Under Bench Dinette Storage (Per Floorplan)
    • Easy Access Booth Dinette Storage Doors
    • 12V 14” Living Room Power Vent Fan
    • 12V 14” Bathroom Power Vent Fan
    • Marine Toilet with Foot Flush
    • ABS Tub/Shower Surround w/Shelves
    • Skylight Above Tub/Shower
    • Glass Step-In Shower w/ABS Surround (Per Floorplan)
    • Medicine Wall Cabinet with Mirror
    • Bedroom Surface Mounts USB Ports (Each Night Stand)
    • Kitchen USB’s & Outlets
    • USB Surface Mounts Near Bunk Beds
    • Solid Master Bedroom Door(s) (Per Floorplan)
    • Solid Bunk Room Door (Per Floor Plan)
    • Mirrored Wardrobes in Master Bedroom
    • Master Bedroom Overhead Cabinets
    • Underbed Storage w/Separation from Outside Front Storage
    • Designer Fitted Master Bed Sheet
    • Teddy Bear Bunk Mats
    • Full Lino in Slide-Outs and Bedrooms (Carpetless)
    • Fireplace w/Electric Heater in the Living Room
    • Ceiling Fans in Living Room and Master Bedroom w/Wall Switch (N/A Master Bedroom 39FKTS)
    • Premium Serta Mattress
    • Washer/Dryer Prep (39MKTS, 39RLTS)
    • Shower/Coat Hooks

    CONSTRUCTION & EQUIPMENT FEATURES

    • Cambered Structural Steel I-Beam Frame
    • Norco Electromagnetic, Powder Coated Chassis
    • Full Length Frame Outriggers
    • 5/8” Tongue & Groove StableDeck Flooring
    • 2”x3” Floor Joists on Approximately 12” Centers
    • 5” Floor To Frame Steel Lag Bolts
    • Darco Subfloor Protective Wrap/Enclosure
    • Seamless Alpha Roof Membrane with Lifetime Warranty
    • Cross-Braced Engineered Roof Trusses w/5” Crown
    • 3/8” Fully Decked Walk-On Roof
    • Screwed Cabinet Construction w/Pocket Bored Lumber Core Stiles
    • 5/8” Plywood Under Bed & Dinette Base
    • 84” Interior Height (7’)
    • Easy-Trac Rack and Pinion Through Frame Main Slide-Out(s)
    • Schwintek Slide Out (Bed)
    • R-7 Fiberglass Insulation Throughout
    • GE 10 Gal. Gas/Electric DSI Water Heater
    • Water Heater By-Pass Winterization Kit
    • 12V Demand Water Pump
    • Premium Exterior Graphics Package
    • Platinum .024” Aluminum Exterior w/.030 Skirt Metal
    • Polished HD Aluminum Fender Skirts
    • Dexter EZ Lube Axles w/Leaf Spring Suspension
    • Self Adjusting Brakes
    • Roto-Cast Holding Tanks
    • Bumper w/ Drain Hose Carrier and End Caps
    • 35,000 BTU Auto-Ignition Furnace w/Wall Thermostat
    • Residential In-Floor Ducted Heat
    • GE 15,000 BTU Fully Ducted A/C
    • 50 AMP Elect. Service
    • Magnetic Hands Free Baggage Door Latches

    SAFETY FEATURES

    • Smoke Alarm
    • LP/CO Gas Detector
    • Fire Extinguisher
    • Fire Escape Windows
    • Entrance Door Window
    • Dead-Bolt Lock on Entry Door
    • SafeRide RV Motor Club (1 YR Roadside Assistance)
  • Specification Imperial Metric
    Cargo Capacity 1,331 lbs 603.73 kg
    Dry Weight 9,669 lbs 4,385.78 kg
    GVWR 11,000 lbs 4,989.52 kg
    Hitch Weight 1,130 lbs 512.56 kg
    Overall Height 11' 8" 3.56 m
    Overall Length 40' 11" 12.47 m
    Overall Width 96" 243.84 cm
    Black Water Tank 40 gal 151.42 l
    Fresh Water Tank 44 gal 166.56 l
    Gray Water Tank 110 gal 416.40 l
Retail Price $55,389
Our price is lower than this

Heartland won't let us display it,
but we can email it to you instantly.

We may contact you via SMS about this request. Msg & data rates may apply. You can unsubscribe at any time.

** All information contained on this website is believed to be accurate at the time of publication. However, during the model year, product revisions occur and manufacturers reserve the right to make these changes without notice. This includes pricing, colors, materials, equipment, and specifications as well as the addition or discontinuation of models shown on this website.
