2027 Chaparral Lite 31BH
About This Chaparral Lite 31BH
Coachmen Fifth Wheel · 36' · Sleeps 10 +
The Chaparral Lite Fifth Wheel is designed for people that enjoy the RV lifestyle, want the comforts and amenities of home but without having to invest in a tank to pull it! Chaparral Lite Fifth Wheels are designed with great aerodynamics and lightweight materials to provide half-ton pickup truck owners an RV that pulls incredibly light but lives exceptionally big! We believe that a natural towing experience – one in which you can forget that you are actually pulling something – can be achieved through great aerodynamics and light weights. Our combination of Alumicage construction and Turn Tec Engineering has taken towability to a whole new level. Chaparral Lite Fifth Wheels are available in single, double and triple slide-out floorplans that have been designed to meet and exceed the needs of today’s RV enthusiast.
Unit details
- Manufacturer
- Coachmen
- Brand
- Chaparral Lite
- Model
- 31BH
- Type
- Fifth Wheel
- Condition
- New
- Year
- 2027
- Interior Decor
- Stoney Beach
- Stock No.
- TEMP32348
- Order No.
- RVN32348
- VIN
- TEMP3234800000000
Specifications
Key measurements for this model, with the manufacturer's full spec sheet below.
Key measurements
- 36'Overall length
- 8,802 lbsDry weight
- 10 +Sleeps
- 1Slide-outs
| Specification | Imperial | Metric |
|---|---|---|
| Cargo Capacity | 2,198 lbs | 997.00 kg |
| Dry Weight | 8,802 lbs | 3,992.52 kg |
| Pin Weight | 1,627 lbs | 737.99 kg |
| Overall Height | 12' 2" | 3.71 m |
| Overall Length | 36' 10" | 11.23 m |
| Overall Width | 96" | 243.84 cm |
| Black Water Tank | 33 gal | 124.92 l |
| Fresh Water Tank | 40 gal | 151.42 l |
| Gray Water Tank | 66 gal | 249.84 l |
As published by the manufacturer for this model.
Equipment & Options
Factory equipment included on this unit as configured.
- Interior Convenience Package
- GETAWAY +™
- 50” HD LED TV in Living W/ Articulating Swing Arm Bracket (40” 235RK)
- High BTU Output, Modern Electric Fireplace (N/A 235RK)
- 13.5 BTU Dual Ducted Main Air Conditioner (+ Wire Frame & Prep For 2nd A/C)
- 10.7 cu. ft. 12V Fridge
- Modern Sound Bar W/ AM/FM Stereo, Bluetooth, & USB
- 60” x 80” Pillow Top Mattress & Bedspread
- Black Out Roller Night Shades
- Secret Hidden Hinge Storage (Select Models)
- On-Demand Water Heater
- GETAWAY +™
- Exterior Convenience Package
- ROAD GUARDIAN +™
- Tri-Tex™ Powder Coated Frame Technology (Up To 5X More Weather Resistance!)
- Road Armor® Suspension By Trail Air® W/ Heavy Duty Shackles & Wet Bolts
- 5,2,1 “No Excuse Guarantee” Radial Tire Warranty + Lifetime Rim
- Protective Rear Bumper W/ 2” Accessory Reciever Hitch
- Exterior Back-Up & Sideview Camera Prep
- 80% Privacy Tint Safety Glass Windows
- WEATHER SHIELD +™
- 6X™ Double Azdel® Aluminum Cage Sidewall System - Vacuum Bonded (R-15+)
- Radiant Pro™ Weather Barrier System
- Insulated & Sectionalized (Easy Access) Underbelly & Gate Valves W/ Circulating Furnace Forced Heat
- Extra Thick Slam Latch Pass-Through Storage Compartment Doors W/ HD Magnet Catches
- 0° Cold Tested & 110° Hot Tested (Extreme Temperature Chamber)
- ROAD GUARDIAN +™
- Roadside Assistance
- Solar Panel with Battery & Charge Controller
- SOLAR SOURCE +™
- Roof Mounted Solar Panel W/ OEM Plug & Play Add-On Panel Option
- Lithium-Ready Converter & Charge Controller
- RV Battery & Storage Box
- LP Quick Connect Port
- Winegard® Air 360+™ HDTV/Radio Dome Antenna W/ WiFi Prepped
- SOLAR SOURCE +™
- TPMS
Included with every new RV
Free- 12V Deep Cycle Battery
- Propane in Tanks
- Dealer Prep
- North American Service
