Catalina Summit 7 154RDX

Coachmen Travel Trailer

Catalina Summit 7 154RDX Travel Trailer by Coachmen

It's never been easier to build the RV of your dreams!

Use the form below to select the equipment & décor that's perfect for you. When you are done, you can get your very own

customized price quote by clicking the "Get The Price" button.

Equipment
Standards
Specifications
  • Factory Standards
    Power Awning w/ Multicolor Customizable LED Strip and Remote, 4,000 Lumen Interior Touch Lighting
    Stainless 12V 10 Cu Ft Refer (184s Only), Stainless Microwave, Stainless 2-Burner Gas Range with Metal Back-Lit Knobs, 13,500 BTU GE High Efficiency A/C with Heat Pump, 6 Gallon GE Gas/Electric Water Heater, Deep Basin Farm Style Sink, (2) USB and (2) 110 outlets
    5/8" Tongue and Groove Stabledeck Flooring + Bunk and Dinette Bases, Screwed Cabinet Construction, Thermofoil Countertops w/ Smooth Drop Edge, ABS Tub/Shower Surround (184BHS, 184RBS Only), 20,000 BTU Furnace, Norco Electromagnetic and Powder Coated Frame
    JBL Aura Head Unit, Multizonal JBL Premium Interior Speaker, Multizonal JBL Premium Exterior Speaker
    Roadside Assistance
    All-In-One Control Panel, Solid Step at Main Entry Door, Universal 600W Solar Prep w/ Installed Roof Panel Port, Siphon 360 Roof Vent, Black Tank Flush, Smooth Metal Radius Front, Front Diamond Plate, Black Glass Friction Hinge Door (N/A 134X Series), Battery Disconnect, Magnetic Baggage Door Latches, Jiffy Sofa w/ Flip Down Cupholder and Easy Access Storage (N/A on all Floorplans)
    Interior Decor
    Factory Options
    Front Radius Lighting and TV
    All-Terrain Tires & Lifted Frame for Increased Clearance with Upgraded Oversized Stabilizer Jacks

  • <!– 11/08/23 –>

    EXTERIOR FEATURES

    • Electric Awning w/Multicolor LED Strip & Remote
    • Black Tank Flush
    • Battery Disconnect Switch
    • Siphon 360 Holding Tank Roof Vent
    • Heavy Duty Standard Tongue Jack
    • (1) 20 lb. LP Tanks
    • LP Quick Connect (N/A 164BHX, 164RBX)
    • Flush Mount Baggage Doors w/Radius Corners
    • Diamond Plate Rock Guard
    • Stabilizer Jacks
    • G20 Tinted Privacy Windows
    • Premium JBL Exterior Speaker
    • Friction Hinge Door
    • Radius Cornered Fiberglass Entry Door
    • Exterior 110V G.F.C.I Protected Receptacle
    • Exterior RG-6 Coax Cabling and Satellite Prep
    • Rain Gutters with Drip Spouts
    • MORryde StepAbove Solid Steps (N/A 164BHX, 164RBX)
    • Rear View Camera Prep
    • Bottle Openers (Exterior Camp Kitchens)
    • Pets - “Leash Link” Quick Hookup D-Ring
    • Universal Solar Prep w/Roof & Chg. Contoller Connections & Wiring
    • Rear Ladder Prep

    INTERIOR FEATURES

    • RV-LINK 4G LTE Remote Connect, WiFi, Booster, and Extender Prep
    • One Control Smart RV Tech Monitor Panel (uses LCI OneControl - App)
    • Premium Audio JBL Aura Cube Multi-Zone Function Media Center
    • Premium JBL Interior Speaker
    • GE 10.7 Cu. Ft. 12V Refrigerator (3.3 Cu. Ft. 12V Refrigerator 164BHX, 164RBX)
    • Seamless Thermofoil Countertops Throughout
    • Deep Basin Farm Style Sink
    • High Rise Bullet Style Kitchen Faucet
    • GE Stainless 2-Burner Cooktop with Metal Back-Lit Knobs
    • Range Hood
    • GE Stainless Microwave W/Glass Turn Table
    • Congoleum Woodplank Linoleum Flooring
    • 4000 Lumin LED Interior Touch Lighting
    • Jiffy Sofa w/Flip Down Cup Holder/Arm Rest
    • Murphy Bed Sofa (Per floorplan)
    • Hard Valance Window Treatments
    • Pedestal Thermofoil Dinette Table (184BHS)
    • Portable Dinette Table (N/A 184BHS, 164BHX, 164RBX)
    • Under Bench Dinette Storage (Per Floorplan)
    • 12V 14” Bathroom Power Vent Fan
    • Marine Toilet with Foot Flush
    • ABS Tub/Shower Surround w/Shelves (N/A 164BHX, 164RBX)
    • Mirror
    • Bedroom Surface Mounts USB Ports (Each Night Stand)
    • Kitchen USB’s & Outlets
    • USB Surface Mounts Near Bunk Beds
    • Master Bedroom Overhead Shelf
    • Designer Fitted Master Bed Sheet
    • Teddy Bear Bunk Mats
    • Full Lino in Slide-Outs and Bedrooms (Carpetless)
    • Shower/Coat Hooks

    CONSTRUCTION & EQUIPMENT FEATURES

    • Cambered Structural Steel I-Beam Frame
    • Norco Electromagnetic, Powder Coated Chassis
    • Full Length Frame Outriggers
    • 5/8” Tongue & Groove StableDeck Flooring
    • 2”x2” Floor Joists on Approximately 12” Centers
    • 4” Floor To Frame Steel Lag Bolts
    • Darco Subfloor Protective Wrap/Enclosure
    • Seamless Alpha Roof Membrane with Lifetime Warranty
    • Cross-Braced Engineered Roof Trusses w/5” Crown
    • 3/8” Fully Decked Walk-On Roof
    • Screwed Cabinet Construction w/Pocket Bored Lumber Core Stiles
    • 5/8” Plywood Under Bed & Dinette Base
    • 78” Interior Height (6’6”)
    • Norco Cable Slide Out
    • R-7 Fiberglass Insulation Throughout
    • GE 6 Gal. Gas/Electric DSI Water Heater
    • Water Heater By-Pass Winterization Kit
    • 12V Demand Water Pump
    • Premium Exterior Graphics Package
    • Platinum .024” Aluminum Exterior w/.030 Skirt Metal
    • Smooth HD Aluminum Radius Front
    • Dexter EZ Lube Axles w/Leaf Spring Suspension
    • Self Adjusting Brakes
    • Roto-Cast Holding Tanks
    • Bumper w/ Drain Hose Carrier and End Caps
    • 19,000 BTU Direct Furnace w/Wall Thermostat
    • GE 13,500 BTU Central A/C
    • 30 Amp Elect. Service w/ 100v 45-Amp Power Covt.
    • Rugged Pro Black Steel Wheels
    • Magnetic Hands Free Baggage Door Latches

    SAFETY FEATURES

    • Smoke Alarm
    • LP/CO Gas Detector
    • Fire Extinguisher
    • Fire Escape Windows
    • Entrance Door Window
    • Dead-Bolt Lock on Entry Door
    • SafeRide RV Motor Club (1 YR Roadside Assistance)
  • Specification Imperial Metric
    Cargo Capacity 1,393 lbs 631.85 kg
    Dry Weight 2,979 lbs 1,351.25 kg
    GVWR 4,372 lbs 1,983.11 kg
    Hitch Weight 372 lbs 168.74 kg
    Overall Length 19' 6" 5.94 m
    Overall Width 90" 228.60 cm
    Black Water Tank 30 gal 113.56 l
    Fresh Water Tank 44 gal 166.56 l
    Gray Water Tank 30 gal 113.56 l
Retail Price $23,054
