Catalina Legacy 323MAZE

Coachmen Travel Trailer

Catalina Legacy 323MAZE Travel Trailer by Coachmen

It's never been easier to build the RV of your dreams!

Use the form below to select the equipment & décor that's perfect for you. When you are done, you can get your very own

customized price quote by clicking the "Get The Price" button.

Equipment
Standards
Specifications
  • Factory Standards
    Front Radius Lighting, Power Awning w/ Multicolor Customizable LED Strip and Remote, 4,000 Lumen Interior Touch Lighting
    Solid Surface Kitchen Countertops, GE 60K BTU Tankless Water Heater, Stainless Glass 12V 10 Cu Ft Refer (GE Residential Style French Door 16.4 Cu. Ft. Refer 323MAZE), Stainless Microwave, Stainless 3-Burner Gas Range with Metal Back-Lit Knobs, 13,500 BTU GE A/C with Heat Pump, Deep Basin Farm Style Sink, Stainless Steel Drying Rack, Glass Rinser, Brick Backsplash, (2) USB and (2) 110 outlets
    10 Ft. Slideout Window, Porcelain Pedestal Toilet, Trundle Sofa IPO Jackknife Sofa (Per Floorplan), Universal 600W Solar Prep w/ Installed Roof Panel Port, All-In-One Control Panel with Dimmer Switch, 360 Siphon Roof Vent, Skylight above Tub/Shower, Bedroom USB and Outlets, 12V Roof Vent and Fan in Living and Bathroom, 5/8" Tongue and Groove Stabledeck Flooring
    Upgraded Aluminum Rims, Aluminum Fender Skirts, Safe-T-Rail Door Assist on Main Entry, Solid Step at Main Entry Door, Enclosed Underbelly, Norco Electromagnetic and Powder Coated Frame, Power Tongue Jack, Black Tank Flush, LP Quick Connect, Hot/Cold Outside Shower, Black Glass Friction Hinge Door, Battery Disconnect, Exterior TV Hookups, Back-Up Camera Prep, Ladder Prep
    JBL Aura Head Unit, 2 Multizonal JBL Premium Interior Speakers, 2 Multizonal JBL Premium Exterior Speakers
    Roadside Assistance
    Interior Decor
    Factory Options
    IPO 13.5 BTU A/C
    General Electric High Efficiency A/C with Heat Pump
    200W Panel w/ 30 AMP Solar Controller
    General Electric High Efficiency A/Cs with Heat Pumps

  • <!– 11/08/23 –>

    EXTERIOR FEATURES

    • Flip Down Cargo Rack w/200 lb. Cap.
    • Electric Awning w/Multicolor LED Strip & Remote
    • Black Tank Flush
    • Battery Disconnect Switch
    • Siphon 360 Holding Tank Roof Vent
    • Electric Tongue Jack
    • Hot/Cold Outside Utility Shower w/ Hands Free Holder
    • (2) 20 lb. LP Tanks
    • Black ABS LP Bottle Cover
    • LP Quick Connect
    • Flush Mount Baggage Doors w/Radius Corners
    • Diamond Plate Rock Guard
    • Stabilizer Jacks
    • G20 Tinted Privacy Windows
    • Front Landscape Picture Window (263FKDS, 283FEDS, 333FKTS)
    • Premium JBL Exterior Speakers
    • Friction Hinge Door
    • Radius Cornered Fiberglass Entry Door
    • Exterior 110V G.F.C.I Protected Receptacle
    • Exterior RG-6 Coax Cabling and Satellite Prep
    • Exterior TV Hookup
    • Rain Gutters with Drip Spouts
    • MORryde StepAbove Solid Steps (Main Entrance Only)
    • Safe-T-Rail Door Assist on Main Entry Door
    • Rear View Camera Prep
    • Full Size Exterior Camp Kitchen (323BHDSCK, 343BHTS)
    • Exterior Camp Kitchen + Storage (263BHSCK, 293QBCK, 293TQBS)
    • Exterior Camp Kitchen (243RBS, 263FKDS, 283RKS, 303RKDS)
    • Bottle Openers (Exterior Camp Kitchens)
    • Pets - “Leash Link” Quick Hookup D-Ring
    • Universal Solar Prep w/Roof & Chg. Contoller Connections & Wiring
    • Rear Ladder Prep

    INTERIOR FEATURES

    • One Control Smart RV Tech Monitor Panel (uses LCI OneControl - App)
    • RV-LINK 4G LTE Remote Connect, WiFi, Booster, and Extender Prep
    • Premium Audio JBL Aura Cube Multi-Zone Function Media Center
    • Premium JBL Interior Speakers
    • GE Stainless 10.7 Cu. Ft. 12V Refrigerator
    • Seamless Thermofoil Countertops Throughout
    • Deep Basin Farm Style Sink
    • Residential Kitchen Faucet w/Pull Down Sprayer
    • Stainless Steel Drying Rack
    • GE Stainless 3-Burner Gas Range with Metal Back-Lit Knobs
    • Range Hood
    • GE Stainless Microwave W/Glass Turn Table
    • Congoleum Woodplank Linoleum Flooring
    • 4000 Lumin LED Interior Touch Lighting
    • SLS (Sit-Lounge-Sleep) Sofa with Interior Storage
    • Bunkroom Jackknife Sofa (293QBCK, 323BHDS, 343BHTS)
    • Designer Wall Lighting Main Slide Room
    • Hard Valance Window Treatments
    • Pedestal Thermofoil Dinette Table
    • Under Bench Dinette Storage (Per Floorplan)
    • Easy Access Booth Dinette Storage Doors
    • 12V 14” Living Room Power Vent Fan
    • 12V 14” Bathroom Power Vent Fan
    • Marine Toilet with Foot Flush
    • ABS Tub/Shower Surround w/Shelves
    • Skylight Above Tub/Shower
    • Glass Step-In Shower w/ABS Surround (Per Floorplan)
    • Medicine Wall Cabinet with Mirror
    • Bedroom Surface Mounts USB Ports (Each Night Stand)
    • Kitchen USB’s & Outlets
    • USB Surface Mounts Near Bunk Beds
    • Solid Master Bedroom Door(s) (Per Floorplan)
    • Solid Bunk Room Door (Per Floor Plan)
    • Full Length Night Stands (N/A Bed Slide-Outs)
    • Mirrored Wardrobes in Master Bedroom
    • Master Bedroom Overhead Cabinets
    • Underbed Storage w/Separation from Outside Front Storage
    • Designer Fitted Master Bed Sheet
    • Teddy Bear Bunk Mats
    • Full Lino in Slide-Outs and Bedrooms (Carpetless)
    • Washer/Dryer Prep (283FEDS, 303RKDS, 313RLTS, 343BHTS)
    • Shower/Coat Hooks

    CONSTRUCTION & EQUIPMENT FEATURES

    • Cambered Structural Steel I-Beam Frame
    • Norco Electromagnetic, Powder Coated Chassis
    • Full Length Frame Outriggers
    • 5/8” Tongue & Groove StableDeck Flooring
    • 2”x3” Floor Joists on Approximately 12” Centers
    • 5” Floor To Frame Steel Lag Bolts
    • Enclosed, Fully Sealed Corrugated Underbelly
    • Darco Subfloor Protective Wrap/Enclosure
    • Seamless Alpha Roof Membrane with Lifetime Warranty
    • Cross-Braced Engineered Roof Trusses w/5” Crown
    • 3/8” Fully Decked Walk-On Roof
    • Screwed Cabinet Construction w/Pocket Bored Lumber Core Stiles
    • 5/8” Plywood Under Bed & Dinette Base
    • 81” Interior Height (6’ 9”)
    • Easy-Trac Rack and Pinion Through Frame Main Slide-Out(s)
    • R-7 Fiberglass Insulation Throughout
    • GE 6 Gal. Gas/Electric DSI Water Heater
    • Water Heater By-Pass Winterization Kit
    • 12V Demand Water Pump
    • Premium Exterior Graphics Package
    • Upgraded Front Graphics Design
    • Platinum .024” Aluminum Exterior w/.030 Skirt Metal
    • Smooth HD Aluminum Radius Front
    • Polished HD Aluminum Fender Skirts
    • Undermount Spare Tire
    • Dexter EZ Lube Axles w/Leaf Spring Suspension
    • Self Adjusting Brakes
    • Roto-Cast Holding Tanks
    • Bumper w/ Drain Hose Carrier and End Caps
    • 35,000 BTU Auto-Ignition Furnace w/Wall Thermostat (N/A 283RKS)
    • 30,000 BTU Auto-Ignition Furnace w/Wall Thermostat (283RKS Only)
    • Residential In-Floor Ducted Heat
    • GE 13,500 BTU Fully Ducted A/C
    • 30 Amp Electric Service w/ 100v 45-Amp Power Covt.
    • 50 Amp Electric Service (Standard on 283FEDS, 303RKDS, 313RLTS, & 343BHTS) *see options
    • Upgraded Aluminum Wheels
    • Magnetic Hands Free Baggage Door Latches

    SAFETY FEATURES

    • Smoke Alarm
    • LP/CO Gas Detector
    • Fire Extinguisher
    • Fire Escape Windows
    • Entrance Door Window
    • Dead-Bolt Lock on Entry Door
    • SafeRide RV Motor Club (1 YR Roadside Assistance)
  • Specification Imperial Metric
    Cargo Capacity 1,792 lbs 812.84 kg
    Dry Weight 9,430 lbs 4,277.38 kg
    GVWR 11,222 lbs 5,090.21 kg
    Hitch Weight 1,022 lbs 463.57 kg
    Overall Height 11' 3" 3.43 m
    Overall Length 37' 0" 11.28 m
    Overall Width 96" 243.84 cm
    Black Water Tank 28 gal 105.99 l
    Fresh Water Tank 44 gal 166.56 l
    Gray Water Tank 60 gal 227.12 l
Retail Price $54,591
Our price is lower than this

Heartland won't let us display it,
but we can email it to you instantly.

We may contact you via SMS about this request. Msg & data rates may apply. You can unsubscribe at any time.

** All information contained on this website is believed to be accurate at the time of publication. However, during the model year, product revisions occur and manufacturers reserve the right to make these changes without notice. This includes pricing, colors, materials, equipment, and specifications as well as the addition or discontinuation of models shown on this website.
